Vehicle night-vision system with 384×288 thermal camera and 7-inch IP69K monitor

This vehicle night-vision system combines a 384×288 thermal camera with a 7-inch waterproof monitor. It is designed for vehicles and equipment used at night or in rain, dust, fog and other demanding conditions.

Thermal camera

• Uncooled 384×288 FPA sensor, fixed athermalized lens and 37.9° × 28.5° field of view.
• PAL output at 50 Hz; the supplier states thermal-contrast detection at distances up to 350 m under suitable conditions.
• Supply: 12–32 V DC; power consumption: below 6 W; protection rating: IP67.
• Operating temperature: -41 °C to +65 °C; dimensions: 64x64x115mm; weight: 750 g.

Monitor

• 7-inch TFT LCD, 800×480 resolution, 400 cd/m² brightness and IP69K protection.
• Two CVBS camera inputs; PAL/NTSC support; OSD controls for brightness, image mirroring, reversing delay and language.
• Supply: 11–32 V DC; maximum power consumption: 5 W; protection against reverse polarity, overvoltage, short circuit and load dump.
• Operating temperature: -20 °C to +70C; dimensions: 220x149x84mm; weight: 700 g.

Camera, monitor and sun visor are included. Warranty: 24 months.
